[ COMPANY ] MAIN TOPIC PRODUCT RAILWAY ELECTRIFICATION Advising. Planning. Delivering. Realising. Maintaining.
Innovative technical solutions by Rail Power Systems, both for the traction systems of alternating and direct current railways and for all types of electrical line installations, have a hand in making rail-guided transport high-performance and also competitive compared with other means of transport. A great deal of attention is paid to terms such as interoperability, sustainability, reliability, As a leading provider of electrical equipment for track-guided transport systems with electrical traction, Rail Power Systems provides its share of efficient and sustainable solutions with its products and services. availability, maintainability and safety during the development and implementation of our products and services. There are decades of experience behind each contact line section and substation. The use of modern technologies, taking current standards into account, quality monitoring, absolute professionalism and passion result in the perfect result for the user and justify their OUR CORPORATE OBJECTIVE SYSTEM PROVIDER FOR RAILWAY ELECTRIFICATION Globalisation of the economy, population growth in conurbations and limited fossil fuel resources require high-performance and energy-efficient transport systems. Whether it’s high-speed railways lines, metro and city train systems, electrically-powered bus networks or special trains: Rail Power Systems' components, systems and services are used in all these systems. trust. The consistent focus on the wishes and requirements of our customers, combined with the ideal combination of standardisation and flexibility guarantees individual solutions with the highest level of efficiency. Experience you can trust. 2 High-speed rail traffic
customised technologies innovative engineering services comprehensive consideration of life cycles procedures and solutions as needed AEG ABB ADtranz Balfour Beatty RPS 1889 1988 1996 2000 2016 EXPERTISE FROM OVER 125 YEARS OF EXPERIENCE We advise, plan, deliver, realise and maintain. RAIL POWER SYSTEMS 3 Regional rail transport Metro systems Light rail and tram systems Industrial railway Mainline systems
Throughout all phases of planning and realisation, our teams concentrate on the optimum system and interface integration and the on-schedule implementation of individual systems. Success requires close cooperation based on partnership and mutual understanding for the objective, We as the system provider take overall responsibility for planning, realising and commissioning your project. the budgets, the project requirements and the system capacities. The numerous successfully executed projects around the world prove that Rail Power Systems knows how to realise the complex relationships in this kind of project. OUR CLAIM THE IDEAL PARTNER AT YOUR SIDE! 4
5
Telecommunication Auxiliary power systems Protection and control technology Power supply Earthing and return circuit Contact line PORTFOLIO QUALITY. EFFICIENCY. DELIVERY RELIABILITY. Electrification of rail-guided transport systems Portfolio overview Advice Planning Production Realisation Commissioning/ supervision Maintenance 6 RAIL POWER SYSTEMS Long-term, successful partnership for optimum collaboration. Decades of experience in Germany, Europe and worldwide. Expertise throughout the entire life cycle of electrified rail-guided transport systems. Complete technological depth from the feasibility study to in-house product development and maintenance concepts.
PROJECT REALISATION Technical competency in realisation and commissioning. Core competencies in the implementation of railway electrification projects with worldwide references. Our own components, systems and software tools. Open to collaborating with local partners. PLANNING AND ENGINEERING SERVICES Planning competence for all electrical railway systems. The combination of sound knowledge of railway electrification and comprehensive practical experience. Covering all life cycle phases from conceptual design and feasibility studies to design, planning, realisation, commissioning and maintenance. Independent advice services including expert reports, simulations and software tools such as TracFeed® Catmos, TracFeed® Catlife, Intelliplan, ProAssist, for example. 7 Power supply Contact line Auxiliary power systems
MAJOR PROJECTS RPS/EN/100/1121 2019 Beijing Daxing, Beijing (MT): Airport Link, double track section between Caoqiao to Daxing, design and delivery of TracFeed® OSS110, China ABS 48 (Geltendrof-Memmingen-Lindau) (ML): Electrification, erection of the Overhead Contact System (VE 04A), 5 new AT stations, Tie Station Lindau and Coupling Station Reutin Germany Höllentalbahn (ML): Electrification, erection of the Overhead Contact System (section east) incl. TracFeed® OLSP, new Tie Stations Donaueschingen and Titisee, Germany Bützow/Schwerin (ML): New construction of 2 SFC stations, Germany KVB Cologne (MT): Renewal of 5 DC substations, Germany ICE-Maintenance Facility Basel (ML): Partial renewal, TracFeed® AEA and retractable TracFeed® OSS, Switzerland ICE Maintenance Facility HamburgEidelstedt (LDT): Renewal of 15 kV Incoming Feeders, TracFeed® AEA, Germany Tel Aviv (MT): LRT Red Line, DC Switchgear, Israel Rotterdam (MT): RET, DC Switchgear, Netherlands Chengdu (MT): Metro-Line 9, DC Switchgear, China Triesdorf-Ansbach-Oberdachstetten (ML): Renewal of the Overhead Contact Line system (Re200/Re100), Germany Radebeuel, Meißener Straße (MT): Dismantling and new construction of the Overhead Contact Line system, Germany 2. S-Bahn Trunk Line Munich (MT): Reconstruction and expansion of the Overhead Contact Line system for the future tunnel, Germany Ankeng, Danhai (MT): TracFeed® SCM Stray Current Monitoring system, Taiwan Freilassing - Hallthurm (ML): Modernisation of the Overhead Contact Line system (Upgrade to Re 100/Re 200), Germany S6 Bad Vilbel (Lot 1+2) (MT): 4-track expansion of the Overhead Contact Line system between Frankfurt West and Bad Vilbel, Germany Salt Lake City (ML): Overhead Contact Line system for Test Track, USA Stuttgart 21 (ML): PA 1.7 Stuttgart Center- Filder area, erection of the Overhead Conductor Rail System incl. transitions to the tensioned OCS, new construction of 4 Tie Posts, lots A and C for 50 Hz and Telecommunication 2020 Seoul, Silim Line (MT): DC Switchgear, South Korea Molnby (ML): Depot, Overhead Conductor Rail TracFeed® OSS, Sweden Beijing (MT): Metro Line 17, Delivery of DC Substation Components, China Zwickau (MT): Framework contract for the delivery, installation and commissioning of 6 compact DC substations, Germany ABS Oldenburg Wilhelmshaven (ML): New construction Tie Post Oldenburg, Substation Rastede and 2 Autotransformer Stations ESTW Ruhland (ML): New construction of an LED track field lighting, Germany Leipzig, Rosa-Luxemburg-Straße (MT): Dismantling and new construction of the Overhead Contact Line system with earthworks, Germany Stuttgart 21 (ML): PFA 1.6a, Connection of the interregional track and its Overhead Contact Line system, Germany Rastatt (ML): Rheintalbahn restoration of the eastern tube of the tunnel Rastatt, Overhead Contact Line system work, Germany 2021 Weimar (ML): New construction of a photovoltaic system for the direct feed into the 16,7 Hz-Overhead Contact Line-system, Germany ESTW Altenburg (ML): Establishment of the execution planning of the Overhead Contact Line system and dismantling, Germany Finnland (ML): Delivery of Overhead Contact Line components Varna und Rasgrad (ML): Delivery of 25-kV Switchgear TracFeed® TAS for the substations, Bulgaria Oldenburg-Rastede (ML): Electrification of the section Bf Oldenburg - Bf Rastede (Railway-km 11,3), Germany MT = Mass Transit ML = Main Line © 2021. All rights reserved by Rail Power Systems GmbH. The specifications set out in this document apply to conventional applications. They do not represent performance limits. This means that divergent specifications may be attained in specific applications. The contractually agreed specifications alone shall apply. We reserve the right to effect technical modifications. TracFeed® is a registered trademark of Rail Power Systems GmbH. RAIL POWER SYSTEMS GMBH Garmischer Straße 35 | 81373 Munich | Germany | T +49 89 41999-0 | F +49 89 41999-270 | info@rail-ps.com | www.rail-ps.com
